توفر الخزائن الطويلة وخزائن الملابس مساحة تخزين أكبر, ولكن غالبًا ما يصعب الوصول إلى منطقة التعليق العلوية. In custom furniture projects, standard lift systems can also create problems when cabinet sizes, installation conditions, or smart control requirements vary from one project to another.
The Angel Particle Motorized Wardrobe Lift is designed for custom wardrobes and B2B projects, with bespoke sizes, a 20 سعة الحمولة كجم, safety protection, and multiple control options.
Custom Wardrobe Lift System for Different Cabinet Sizes
Standard hardware does not always fit sloped ceilings, narrow wardrobes, or floor-to-ceiling cabinets.
The Angel Particle Wardrobe Lift System can be customized for internal cabinet widths of approximately 300–1200 mm. Matte Black, Champagne Gold, Space Silver, and Gunmetal Grey finishes are available for different furniture styles.
For OEM/ODM projects, cabinet drawings can be checked before production to confirm product dimensions and installation space.
20 kg Load Capacity with Safety Protection
The system uses dual Hall-synchronized motors with a stable load capacity of 20 كجم (44 lbs) and operating noise of ≤45 dB.
During operation, built-in obstacle detection monitors abnormal resistance. If the rail encounters an obstruction, it stops and reverses upward instead of continuing to push against it.
This is especially useful in finished custom cabinetry, where protecting cabinet panels, doors, and the lifting mechanism is important.
Multiple Control Options for Smart Wardrobes
Touch control is standard, while remote control, voice control, and Tuya Smart App control are available as options.
For whole-home automation projects, dry-contact interfaces can also be used for integration with compatible Zigbee, Wi-Fi, or Matter solutions.
This allows furniture manufacturers and smart-home companies to choose the control method according to the project rather than being limited to one fixed configuration.
Pre-Assembled for Easier Installation
Around 80% of the main transmission components are pre-assembled at the factory.
Installers mainly need to position, secure, and connect the unit on site, reducing unnecessary assembly and adjustment inside finished cabinetry.
The system also supports 100–240V input, making it suitable for projects in different international markets.
Motorized Wardrobe Lift Specifications
| Item | Specification |
|---|---|
| منتج | رفع خزانة الملابس الآلية |
| Model | TSY Basic Model |
| Custom Width | Approx. 300–1200 mm |
| سعة التحميل | 20 كجم / 44 lbs |
| Movement | 90° Lowering |
| Motor | Dual Hall-Synchronized Motors |
| Noise | ≤45 dB |
| Control | Touch / Remote / Voice / Tuya App |
| LED | Optional 4000K |
| Input | 100–240V |
| OEM/ODM | متاح |
OEM/ODM Electric Wardrobe Lifts
Angel Particle manufactures Electric Wardrobe Lifts for custom furniture manufacturers, wardrobe brands, hardware distributors, and project buyers.
For custom projects, send us your cabinet dimensions, required quantity, finish, control method, and destination market. Cabinet drawings can also be provided for dimensional checking.
Request a Sample or Project Quotation
Need a رفع خزانة الملابس الآلية for your next wardrobe or walk-in closet project?
Contact Angel Particle for samples, custom sizing, OEM/ODM support, and factory-direct B2B quotations.
